Function description
The
socket is ordinary converter,with two output 5V2A power USB power
supply at the same time,can be very convenient in use electrical
appliances and recharge the equipment at the same time,such as digital
products like Iphone Ipad,MP3,MP4 etc.The charge apply to full range of
international AC output,no-load power consumption less than 0.3W,with
short circuit,overload,over-voltage protection,can be convenient for
your life and save more energy
Timer Control Time Adgustment
1.Press the power switch 1 time,the 1HOUR LED will light on.The Timer into ON mode,USB and control socket output ON .
2.Continuously
press the power switch the LED light on,the Countdown mode and LED
light on will cycle change from 1HR,2HR,4HR,6HR,8HR,10HR.
3.Choose
you need countdown time mode,the mode LED will lighto on,start
countdown until countdown time finish,the control output and USB change
to OFF
4.Then the countdown is start,The Time indicate LED will from high to low auto change until Countdown finish off.
Failure analysis:
1.check whether the power supply connection is good
2.check whether the USB cable is loosen
Warning Note:
1.Use indoor and dry location ONLY
2.The load max does not exceed 15A 3600W
3.This product does not convert voltage please do not miss use DO NOT exceed the maximum loading of 3600 Watts 15A
4.Always have earth connection for safety reason
5.If in doubt please consult with a qualified electrician
